Description
Features
220W Power Output
Dolby Digital embedded
Wireless music streaming via Bluetooth
One cale connection with HDMI ARC
General Specifications
• Power supply: 100 - 240VAC, ~ 50/60Hz
• Total speaker power output (Max. @THD 1%): 220W
• Soundbar power output (Max. @THD 1%): 2 x 52W
• Subwoofer power output (Max. @THD 1%): 116W
• Soundbar transducer: 2 x (48 x 90)mm racetrack driver + 2 x 0.5" tweeter
• Subwoofer transducer: 5.25", wireless sub
• Operating temperature: 0°C - 45°C
Audio Specifications
• Max SPL: 82dB
• Frequency response: 40Hz - 20kHz
• Audio inputs: 1 Optical, Bluetooth (USB is for Service only.)
Dimensions
• Soundbar dimensions: (W x H x D)900 x 67 x 63mm
• Subwoofer dimensions: (W x H x D)170 x 345 x 313mm
• Soundbar Weight: 1.65kg
• Subwoofer Weight: 5kg
• Packaging dimensions: (W x H x D)975 x 195 x 445mm
• Packaging weight (Gross weight): 8.5kg
Control and Connection
• Bluetooth version: 4.2
• Bluetooth profile: A2DP V1.3/AVRCP V1.5
• Bluetooth frequency range: 2402MHz - 2480MHz
• Bluetooth max. transmitting power: <0dbm (EIRP)
• Modulation type: GFSK, π/4 DQPSK
• 2.4G Wireless frequency range: 2400 - 2483MHz
• 2.4G Max. transmitting power: 3dBm
• USB port: Type A
• USB rating: 5VDC/ 0.5A
• Supporting file format: mp3, wav
• MP3 Codec: MPEG 1 Layer 2/3
• MPEG 2 Layer 3: Yes
• MPEG 2.5 Layer 3: Yes
• MP3 sampling rate: 16kHz - 48kHz
• MP3 bitrate: 80kbps - 320kbps
• 80kbps - 160kbps (MPEG 2.5 Layer 3): Yes
• WAV sample rate: 16kHz - 48kHz
